Features:
Ultralow Supply Current: 850nA
Low Drift:
A Grade: 10 ppm/°C Max
B Grade: 20 ppm/°C Max
High Accuracy:
A Grade: 0.05% Max
B Grade: 0.1% Max
Long-Term Drift: 15 ppm/kHr (LS8 Package)
No Humidity Sensitivity (LS8 Package)
High Output Drive Current: 5mA Min
Low Dropout Voltage: 10mV Max
Fully Specified from: -40°C to 85°C
Operational from: -55°C to 125°C
Wide Supply Range: Up to 18V
Reverse Input/Output Protection
Available Output Voltage Options:
1.25V, 2.048V, 2.5V, 2.8V, 3V, 3.3V, 4.096V, and 5V
Available Packages:
Low Profile (1mm) ThinSOT™
(2mm x 2mm) DFN
High Stability Hermetic (5mm x 5mm) LS8 Packages

Applications:
Precision A/D and D/A Converters
Portable Gas Monitors
Battery- or Solar-Powered Systems
Precision Regulators
Low Voltage Signal Processing
Micropower Remote Sensing
